YBT-H Series Flameproof Three-phase Marine Induction Motor for Ventilator

YBT-H the motors are designed and manufactured according to National Standard GB3836.1“Electric apparatus for explosive gas atmosphere-part 1: general requirement” and GB3836.2“Electric apparatus for explosive gas atmosphere –part2: flameproof enclosure “d”” It has the feature of high efficiency. Big rotation moment .low noise and convenient protection. The protection type of the motor is Exd II BT4, EdII CT4, It can be used on the mixture air of easy-ignition or steam and atmosphere that can be brought on explosion. This series can be matching with CBZ-II flameproof ventilating machine on board ship.

YBT-H Series Flameproof Three-phase Marine Induction Motor for Ventilator Operation Condition

Ambient Temperature: -25~45℃;
Altitude: <1000m;
Relative Humidity: ≤95%;
Inclination and Swing: ±22.5℃(The longitudinal and lateral tilt might happen);
Oil-mist, salt-mist, fungus and sea water exist;
Shock and vibration might happen during shipping;
In air there might be existent explosive mixture which compounds with temperature class T1~T4 easy-ignition air or steam and air.

YBT-H Series Flameproof Three-phase Marine Induction Motor for Ventilator Basic Parameters

Power: 0.75~55kW
Voltage: 380V 440V or 660V
Frame Size: 80~250
Frequency: 50Hz or 60Hz
Ambient Temperature: -20℃~40℃
Insulation Class: F
Degree of Protection: IP55、IP56
Explosion-proof Mark: Exd IICT4 Gb
Duty: S1
Connection: 3kW or less than 3kW connected Y, the others connected △
Temperature rise of winding(resistance method)shouldn’t exceed 80K, allowed temperature of bearing(thermometer method)shouldn’t exceed 90℃.

YBT-H Series Flameproof Three-phase Marine Induction Motor for Ventilator Manufacturer

Our explosion-proof motors include: YBT-H Series Flameproof Three-phase Marine Induction Motor for Ventilator, YB3 explosion-proof motor, YBX3 explosion-proof motor, YBBP variable frequency explosion-proof motor, YFB3 dust explosion-proof motor, YBF3 explosion-proof motor for coal mine fan, YBK3 explosion-proof motor for mine, YB, YB2 (H355-H900) series high-voltage medium-sized explosion-proof motor Type three-phase asynchronous motor (6KV, 10KV, stainless steel extended shaft explosion-proof motor and other models.

YBT-H Series Flameproof Three-phase Marine Induction Motor for Ventilator Ordering Information

1. Specify the type motors, rated output, synchronous speed, voltage, frequency, mounting arrangement,explosion-proof group, degree of protection the cable entry form of the terminal box and so on. number of poles, voltage, frequency, mounting, arrangements and other requirements.
2. If you have special requirements for the motor noise, degree of protection and greasing and draining oil debices of the bearings, etc. Pleasenote them in the contract.
3. this catalog is only for user reference, and specific data are subject to change without notice.
